Aune SC1 OCXO Clock Silver

The Aune SC1 is a high performance external clock embedding an optimized audio architecture, including the use of an OCXO oscillator and an FS-1 frequency synthesizer designed by Titans Audio Lab, with efficient power supply and signal isolation. It provides two 10M sine wave outputs and two 10M square wave outputs with a phase synchronization of less than 0.00001°.

Average votes for this product
5.0 / 5
  Based on 2 customers reviews.

By buying this product you get 69 loyalty points


Reference : 17431
New product

699,00 €tax incl.

582,50 € tax excl.
Including 0,05 € for green tax

- +


Shipping date: 04-12-2024.

Orders placed before 12h (GMT+1) will generally be shipped the same day (working day).

Add to wishlist
Livraions depuis la france

Livraison depuis la france Livraison depuis la france Livraison depuis la france

Livraison depuis la France
Facturation France
SAV France

2 Years warranty

Accessories for this product

Find here a selection of useful and/or essential accessories for this product. These are specially selected by the Audiophonics team according to the characteristics of the product.


More info

Aune SC1

Clock 10MHz OCXO Sine Signal / Square Signal Silver

Aune SC1 Horloge 10MHz OCXO Argent

The Aune SC1 is a high performance external clock embedding an optimized audio architecture, including the use of an OCXO oscillator and an FS-1 frequency synthesizer designed by Titans Audio Lab, with efficient power supply and signal isolation. It provides two 10M sine wave outputs and two 10M square wave outputs with a phase synchronization of less than 0.00001°. It can also be powered in DC or AC. Its power supply stage incorporates a high-current, low-noise LDO to provide a clean and stable electrical signal to the OCXO clock.

Aune SC1 Horloge 10MHz OCXO Argent
1Screen
2ON/OFF outputs button
310MHz sine signal outputs
410MHz square signal outputs
512VDC power supply input
6Power button
7100-240VAC power input
8WCK outputs

Technical characteristics

Specifications
Product typeClock
Outputs4* 10MHz outputs on BNC connectors
Output power> 7dBm (50Ω)
Output waveform2* square signal
2* sine signal
Frequency accuracy< ±0.02ppm
Jitter< 200Fs BW 1Hz-1MHz
Phase noise (10MHz)< -100dBc @ Offset 1Hz
< -125dBc @ Offset 10Hz
< -145dBc @ Offset 100Hz
< -155dBc @ Offset 1kHz
< -160dBc @ Offset > 10kHz
Warm-up timeBasic: 5min
General
Supply voltage100-240VAC
12VDC 2A
Operating temperatureNormal operating: 0°C-50°C
Optimum operating: 15°C-35°C
Dimensions288*211*63mm
ColorBlack
Package1* Aune SC1 Silver
1* Power cable

Delivery

We deliver all over France, and internationally.
To find out the amount of shipping costs, simply go to your cart once you have added the desired products.
To discover our different services and delivery options, click on the following logos :

Livraison par Colissimo Livraison par UPS Express Saver Livraison par DPD
Only registered users can post a review. Log in or create an account .
Average votes
5.0 / 5
2 reviews
Why write products reviews ?
You can share your feelings about products and help other people by sharing your experience

Note :
 5/5
Date :
Excellent
Branchée sur un streamer/dac elle apporte beaucoup.
Il ne faut pas négliger le câble, le passage d'un câble basique rg58 50ohms à un plus qualitatif est indispensable pour en tirer le meilleur, sans vous rateriez quelque chose, ce serait dommage :p
 (0)
 (0)
This review has been posted for AUNE SC1 Clock 10MHz OCXO Sine Signal / Square Signal Silver
Note :
 5/5
Date :
Indispensable!
J'ai déjà laissé un avis très positif sur l'horloge Aune SC1 noir que j'ai acheté en Décembre 2023....tellement content que j'ai acheté une seconde horloge Aune en silver pour mon second système....c'est dire! A signaler qu'il ne faut jamais débrancher l'horloge...elle met très longtemps à retrouver son optimum....et si vous pouvez l'alimenter avec une alimentation extérieur de qualité, c'est encore meilleur!
L'Aune silver est branchée sur mon second Teac ud701n, mais je l'ai testée aussi sur un Esoteric N-05XD...superbe!!
 (0)
 (0)
This review has been posted for AUNE SC1 Clock 10MHz OCXO Sine Signal / Square Signal Silver
