ALLO DIGIONE Raspberry Pi 2 / 3 / 4 Digital Interface SPDIF

Average votes for this product
4.9 / 5
  Based on 17 customers reviews.

By buying this product you get 13 loyalty points


Reference : 12067
New product

135,00 €tax incl.

112,50 € tax excl.
Including 0,01 € for green tax

This product is discontinued
Livraions depuis la france

Livraison depuis la france Livraison depuis la france Livraison depuis la france

Livraison depuis la France
Facturation France
SAV France

2 Years warranty

Our choice

No featrued products

Accessories for this product

Find here a selection of useful and/or essential accessories for this product. These are specially selected by the Audiophonics team according to the characteristics of the product.


More info

ALLO DIGIONE

Digital interface

Interface digitale Allo DigiOne

High quality digital interface

The Allo DigiOne digital interface is currently the best SPDIF digital output for Raspberry Pi. It will connect directly to the GPIO of your Raspberry Pi 2 / 3 / 4 to improve the performance of your system, lowering the jitter to a minimum. Equipped with a DIR WM8805 chip, it ensures the digital transfer of the Raspberry Pi with High Fidelity.

Indeed, the DigiOne includes high quality components that will take your music to new horizons with 10 LDO regulators, 12 LPF filters, low noise DC/DC converters, galvanic isolation, low drift NDK oscillators (clocks). The outputs of the Raspberry Pi and DIR WM8805 are separated by a digital isolator to avoid degrading the signal.

The DigiOne benefits from a 75 Ohm BNC output and a 192 kHz 24-bit digital Coaxial RCA output. The jitter rate for a SPDIF interface is one of the lowest on the market with 0.4PS. Most of the competitors are over 1000ps (1ns)! The noise is reduced to 50uV.

Download Volumio for DigiOne by clicking here
Analyze report AP - RCA Analyze report AP - BNC Jitter measurements MCLK Output Data SPDIF BNC Output Data SPDIF RCA

DigiOne review by
The Hans Beekhuyzen Channel"

Parts supplied allo Digione

Module provided with spacers


You will find your Digione a set of spacers and screws M2.5 x 5mm in black light plastic. These elements allow a clean installation on SBC

Connectors
InputRaspberry Pi GPIO
Outputs1x BNC
1x RCA Coaxial
Components
Régulators10x LDO
Filters12x LPF
DC/DC converter
Digital Galvanic Isolator-
WM8805 Chip-
Buffers-
OscillatorsNDK
Specifications
Jitter0.6ps
Noise level50uV
Dimensions65x55mm
Spacing57x48mm

Data sheet
InputGPIO
OutputBNC
OutputCoaxial SPDIF
DAC / ADC ChipWM8805
Max sampling rate192kHz
Interface chipWM8805

Delivery

We deliver all over France, and internationally.
To find out the amount of shipping costs, simply go to your cart once you have added the desired products.
To discover our different services and delivery options, click on the following logos :

Livraison par Colissimo Livraison par UPS Express Saver Livraison par DPD
Only registered users can post a review. Log in or create an account .
Average votes
4.9 / 5
17 reviews
Why write products reviews ?
You can share your feelings about products and help other people by sharing your experience

Note :
 5/5
Date :
Allo Digione
Bona millora sobre Raspberry PI 4, so més net i sensació d'amplitud sonora millorada. En tot cas, veient el que es paga per un streamer és una compra molt assumible.
L'enviament va trigar 5 dies en arribar a casa.

Tot correcte,
 (0)
 (0)
This review has been posted for ALLO DIGIONE Raspberry Pi 2 / 3 / 4 Digital Interface SPDIF
Note :
 5/5
Date :
extraordinaire carte son
superbe carte avec une sonorité époustouflante.
livraison super rapide.Je recommande+++
 (0)
 (0)
This review has been posted for ALLO DIGIONE Raspberry Pi 2 / 3 / 4 Digital Interface SPDIF
Note :
 5/5
Date :
Pour ne plus utiliser l'usb du dac Khadas
L'interface digitale Allo DigiOne m'a permis d'envoyer directement le signal numérique vers l'entrée RCA de mon dac Khadas sans passer par l'entrée usb qui n'est plus utilisée.
Mon dac Khadas a sa propre alimentation externe, une allo (Référence : 11638), raccordée aux pins 1 (+) et 21 (-).
Une façon élégante et économique d'enterrer la polémique sur la dégradation de la qualité sonore si on passe par l'usb.
Dans Volumio il faut sélectionner I2S et Digione dans les paramètres de lecture, il faut aussi savoir que la commande de volume ne sera plus opérationnelle dans son interface.
 (0)
 (0)
This review has been posted for ALLO DIGIONE Raspberry Pi 2 / 3 / 4 Digital Interface SPDIF
Note :
 5/5
Date :
Very good
 (0)
 (0)
This review has been posted for ALLO DIGIONE Raspberry Pi 2 / 3 / 4 Digital Interface SPDIF
Note :
 4/5
Date :
Allo DigiOne - good, but that's it
Allo DigiOne was easy to install, immediately recognized in PiCorePlayer, and functions well with the Rpi 3B+.
Has an always-on bright green LED that can be annoying, covered mine with some black tape on the case I ordered (case had air vents it shone through).
Sound quality is good, no noise or jitter audible to me (using digital interlink to a DAC to a tube amp and the ~11 Euro Allo switching PSU).
At this price/performance, I can't justify getting the way more expensive Signature HAT in my upper mid-fi setup.
 (1)
 (0)
This review has been posted for ALLO DIGIONE Raspberry Pi 2 / 3 / 4 Digital Interface SPDIF
