AUNE X8 DAC FPGA Altera Max II 32bit 768kHz DSD512 XMOS Silver

The Aune X8 is a high-performance DAC, compatible with high-resolution files up to 32bit PCM 768kHz and DSD512. The conversion is done using an Altera Max II FPGA chip, specifically programmed by Aune to achieve high conversion quality.

Average votes for this product
5.0 / 5

By buying this product you get 23 loyalty points


Reference : 15044
New product

239,00 €tax incl.

199,17 € tax excl.
Including 0,05 € for green tax

This product is discontinued
Livraions depuis la france

Livraison depuis la france Livraison depuis la france Livraison depuis la france

Livraison depuis la France
Facturation France
SAV France

2 Years warranty

More info

This product has been replaced by the new version, the AUNE X8 XVIII BT MAGIC DAC FPGA Bluetooth aptX HD LDAC.

Aune X8

DAC FPGA Altera Max II 32bit 768kHz DSD512

Aune X8 DAC FPGA Altera Max II 32bit 768kHz DSD512

The Aune X8 is a high-performance DAC, compatible with high-resolution files up to 32bit PCM 768kHz and DSD512. The conversion is done using an Altera Max II FPGA chip, specifically programmed by Aune to achieve high conversion quality. The device benefits from a complete range of connectors, with USB-B, Coaxial and Optical inputs. The audio stream can then be output to an RCA Pre-Out or RCA Line output.

Aune X8 DAC FPGA Altera Max II 32bit 768kHz DSD512

Adapt the X8 to your preference!

A special feature of the Aune X8 is that the OPA sound can be easily interchanged with another model to adapt the sound reproduction to your listening experience. The underside of the device shows the OPA in place, mounted on a DIP8 bracket, and is delivered with an extraction clip and a storage box for your OPA.

The device also offers a series of 7 filters to adjust its sound signature more and more precisely.

Aune X8 DAC FPGA Altera Max II 32bit 768kHz DSD512 Aune X8 DAC FPGA Altera Max II 32bit 768kHz DSD512
Aune X8 DAC FPGA Altera Max II 32bit 768kHz DSD512

FPGA

The Altera Max II FPGA is the true heart of this Aune X8. Its program, developed and optimized by Aune, allows a particularly efficient conversion of digital streams.

Technical characteristics

Specifications
Product typeDAC
Conversion chipFPGA Altera Max II
USB InterfaceXMOS U308
Inputs1x USB-B
1x Optical Toslink
1x Coaxial
Outputs1x RCA Pre-Out
1x RCA Line out
Supported sampling ratesUSB : PCM up to 32bit 768kHz, DSD up to DSD512
Coaxial : PCM up to 24bit 384kHz, DSD DoP up to DoP128
Optique : PCM up to 24bit 192kHz, DSD DoP up to DoP64
Output level (line out)2Vrms
Frequency response (line out)20Hz - 20kHz ±0.2dB
SNR (line out)117dB
THD+N (line out)0.0006%
General
Housing materialAluminum
Dimensions145 x 171 x 45mm
ColorSilver
Package1x Aune X8
1x USB Cable
1x Power supply

Data sheet
InputSPDIF
InputUSB
InputOptical
OutputRCA
DAC / ADC ChipAltera MAX II
Max sampling rate768kHz
Max sampling rateDSD512
ColorSilver
NetworkingNo
Remote ControlNo
