TOPPING E70 DAC ES9028Pro XMOS XU316 Bluetooth 5.1 aptX Adaptive LDAC 32bit 768kHz DSD512 Silver
By buying this product you get 29 loyalty points
![[GRADE A] AUNE S9C PRO DAC 2x ES9068AS Discreet Headphone Amplifier 5W Bluetooth 32bit 768kHz DSD512 MQA Back](https://www.audiophonics.fr/64487-thumb_default/aune-s9c-pro-dac-2x-es9068as-discreet-headphone-amplifier-5w-bluetooth-32bit-768khz-dsd512-mqa-back.jpg)
![[GRADE A] Mono Power Amplifier Modules LM3886 with Heatsinks 2x120W / 8 Ohm (Pair)](https://www.audiophonics.fr/64212-thumb_default/mono-power-amplifier-modules-lm3886-2x120w-8-ohm-pair.jpg)
Topping E70
DAC ES9028Pro XMOS XU316 Bluetooth 5.1 aptX Adaptive LDAC 32bit 768kHz DSD512 Silver
Topping offers with its E70 a powerful DAC with an accurate design. A model capable of offering a rich and precise sound reproduction, combined with smart and practical features, such as Bluetooth, a 12V trigger or an adaptable output level.
ES9028Pro DAC
The Topping E70 embeds a digital to analog conversion stage based on an ESS ES9028Pro chip. This 32bit DAC with eight channels benefits from the HyperStream II architecture and ensures a high quality sound reproduction, marked by a beautiful transparency and precision.
A brand new I/V conversion circuit
The E70 also benefits from an all-new I/V conversion circuit, designed to ensure low distortion and low noise, while taking up less space. This is pushed to its limits to allow the DAC to reveal its full potential.
Bluetooth 5.1
Equipped with a Qualcomm QCC5125 Bluetooth 5.1 receiver chip, the E70 allows you to remotely stream your music directly from your smartphone or tablet. It also supports the high-resolution transmission codecs aptX, aptX HD, aptX Adaptive and LDAC, guaranteeing high-quality playback over Bluetooth.
XMOS XU316 USB Interface
The USB input of the Topping E70 is associated with a latest generation XMOS XU316 interface with custom Thesycon driver. This powerful interface supports high resolution audio streams, up to PCM 32bit 768kHz and DSD512, for a very high quality listening.
12V Trigger
The E70 integrates a 12V trigger with active (trigger output) and passive (trigger input) control. With only a simple 3.5mm jack cable, the Topping E70 can be switched on and off in sync with your other equipment with a 12V trigger interface.
Selectable output modes
The E70 provides balanced XLR and single-ended RCA output. The input is selectable and allows to activate only one or both simultaneously. In addition, Topping offers a smart feature, allowing you to adjust the level of these outputs according to your use and desired integration. Thus, the level of the XLR output can be changed from 4V to 5V and the RCA output from 2V to 2.5V.
| 1 | ON-OFF / Input selection button |
| 2 | Screen |
| 3 | Volume button |
| 4 | Coaxial input |
| 5 | Bluetooth antenna connector |
| 6 | 12V Trigger input |
| 7 | Balanced XLR output |
| 8 | Single-ended RCA output |
| 9 | Optical Toslink input |
| 10 | USB-B input |
| 11 | 12V Trigger output |
| 12 | Power connector |
| 13 | Power button |
Technical characteristics
| Specifications | |
|---|---|
| Product type | DAC |
| Inputs | Bluetooth 5.1 1x USB-B 1x Coaxial 1x Optical Toslink |
| Outputs | 1x Single-ended stereo RCA 1x Balanced stereo XLR |
| DAC Chip | ES9028Pro |
| Bluetooth receiver | QCC5125 |
| USB Interface | XMOS XU316 |
| Supported Bluetooth codecs | AAC, SBC, aptX, aptX HD, aptX LL, aptX Adaptive, LDAC |
| Supported sampling rates | USB : PCM up to 32bit 768kHz, Native DSD up to DSD512, DSD DoP up to DSD256 Optical / Coaxial : PCM up to 24bit 192kHz, DSD DoP up to DSD64 |
| Measurements | ||
|---|---|---|
| Paramètres DAC E70 (Sortie ligne / Entrée USB à 96kHz) | ||
| RCA | XLR | |
| THD+N @ 1kHz, A-Weighted | < 0.00008% | < 0.00006% |
| THD @ 20Hz-20kHz, 90kBw, Non-Weighted | < 0.0007% | < 0.0002% |
| SNR @ 1kHz, A-Weighted | 126dB | 132dB |
| Dynamic range @ 1kHz, A-Weighted | 126dB | 132dB |
| Frequency response | 20Hz-20kHz (±0.2dB) 20Hz-40kHz (±0.4dB) | 20Hz-20kHz (±0.2dB) 20Hz-40kHz (±0.4dB) |
| Output level | 2.1Vrms @ 0dBFS (4V Mode ) 2.5Vrms @ 0dBFS (5V Mode) | 4.2Vrms @ 0dBFS (4V Mode) 5Vrms @ 0dBFS (5V Mode) |
| Noise (A-Weighted) | < 1.3µVrms | < 1.3µVrms |
| Crosstalk | -133dB @ 1kHz | -149dB à 1kHz |
| Channels balance | 0.3dB | 0.3dB |
| Output impedance | 50Ω | 100Ω |
| General | |
|---|---|
| Color | Silver |
| Dimensions | 200*138*4mm |
| Package | 1x Topping E70 1x Remote cotnrol 1x USB cable 1x Power cable 1x Bluetooth antenna |
| Input | SPDIF |
| Input | Bluetooth |
| Input | USB |
| Input | Optical |
| Output | XLR |
| Output | RCA |
| DAC / ADC Chip | ES9028PRO |
| Max sampling rate | DSD512 |
| Max sampling rate | 768kHz |
| Color | Silver |
| Networking | No |
| Remote Control | Yes |
