iBasso DX160
HiFi Digital Audio Player DAP 2x CS43198 Bluetooth 5.0 32bit 384kHz DSD Black
The DX160, iBasso's new mid-range DX HiFi player, offers exceptional audio performance and many features. Its high-quality design combines an elegant design, rich audio playback and an ergonomy designed to provide an intuitive experience.
Android 8.1 Oreo & CPU Octa Core
At the heart of the DX160, an Octa Core processor combined with 2GB of RAM powers the operating system, Android 8.1 Oreo, to deliver a smooth and intuitive experience. This flexible OS allows you to install compatible applications to adapt the user experience to your desires and needs.
The Google Play Store is not available on the DX160, the application installation is done directly via .apk files.
Dual CS43198 DAC
The digital-to-analog conversion stage includes two DAC CS43198 chips designed by Cirrus Logic, allowing independent conversion on each channel. These chips provide very good audio performance with a dynamic range measured at -130dB and a THD+N at -115dB, for accurate, lively and rich reproduction.
In addition, the CS43198s are particularly suitable for battery-powered systems, as they are optimized to provide low power consumption and therefore maintain a good range.
Finally, these converters support high sampling rates, allowing PCM audio streams up to 32bit 384kHz and DSD up to DSD256 to be played.
A large screen, an intuitive interface
The Topping DX160 features a large 5" screen with a resolution of 1080p (Full HD), allowing you to display all the information you need to navigate your applications and audio files. The Android interface, particularly intuitive, offers a quick and easy way to get started with the walkman.
A consequent autonomy
With its 3200mAh battery, the DX160 has no battery life problems. Allowing continuous reading for 13 hours (after full charge), it is the ideal companion to accompany you on your travels. In addition, it incorporates Quick Charge 3.0 (QC3.0) technology, allowing it to be recharged very quickly.
The autonomy depends on the resolution of the files played and the impedance of the headphones / headphones used.
Dual outputs, WiFi and Bluetooth
The DX160 has two output connectors. On one side a 4.4mm TRRRS (Pentaconn) symmetrical jack and on the other side a 3.5mm jack connector acting as both Line and Coaxial output. The Topping DAP also supports remote transmission via WiFi and Bluetooth 5.0.
Technical characteristics
Specifications |
---|
Product type | DAP |
OS | Android 8.1 |
DAC | 2x CS43198 |
Outputs | 1x Balanced Jack 4.4mm 1x Jack 3.5mm Line Out / Power Out / Coaxial 1x USB |
Screen | 5.0" 1080p |
CPU | Octa Core |
RAM | 2Go |
ROM | 32Go |
WiFi | 802.11 b/g/n/ac (2.4GHz/5GHz) |
Bluetooth | 5.0 |
Battery | 3200mAh |
Autonomy | 13h (playback time varies depending on the resolution of the files being played and the charge of the headphones or headphones). |
Quick charge | QC3.0 PD2.0 |
Supported audio formats | MQA, APE, FLAC, WAV, WMA, AAC, ALAC, AIFF, OGG, MP3, DFF, DSF, DXD, CUE, ISO, M3U, M3U8, MQA |
Balanced Jack 4.4mm output |
---|
Output voltage | 6.4Vrms |
Frequency response | 10Hz - 40kHz +/-0.15dB |
SNR | 130dB |
THD+N | 0.00022% (no load, 3Vrms) 0.00022% (32Ω, 3Vrms) |
Crosstalk | -125dB |
Single-ended Jack 3.5mm output |
---|
Output voltage | 3.2Vrms |
Frequency response | 10Hz - 40kHz +/-0.15dB |
SNR | 125dB |
THD+N | 0.0004% (no load, 2Vrms) 0.0007% (32Ω, 2Vrms) |
Crosstalk | -115dB |
Line output |
---|
Output voltage | 3.2Vrms |
Frequency response | 10Hz - 40kHz +/-0.15dB |
SNR | 125dB |
THD+N | 0.00035% (no load, 2Vrms) |
Crosstalk | -113dB |
General |
---|
Dimensions | 113 x 69 x 15mm |
Weight | 178g |
Color | Black |
