HIFIMAN GA-10 Headphone Amplifier

New
The GA-10 is a HiFiMAN headphone amplifier developed in collaboration with GoldenWave. It uses ECC83/12AX7 tubes for its preamplification stage and EL84 tubes for its power stage. The use of these tubes results in a smooth, warm sound reproduction.

No customer reviews yet, login to write a review.

By buying this product you get 171 loyalty points


Yes, notify me when available !
Reference : 20041
New product

1 710,00 €tax incl.

1 425,00 € tax excl.
Including 0,05 € for green tax

- +


Available on order
Livraions depuis la france

Livraison depuis la france Livraison depuis la france Livraison depuis la france

Livraison depuis la France
Facturation France
SAV France

2 Years warranty

Accessories for this product


More info

HIFIMAN GA-10 Headphone Amplifier with ECC83/12AX7 and EL84 Tubes

HIFIMAN GA-10 picture

The GA-10 is a HiFiMAN headphone amplifier developed in collaboration with GoldenWave. It uses ECC83/12AX7 tubes for its preamplification stage and EL84 tubes for its power stage. The use of these tubes results in a smooth, warm sound reproduction. In addition, the GA-10 is capable of delivering an output power of 600mW at 32 ohms. Added to this is a 3-step gain control for compatibility with headphones and earphones available on the market. The back of the GA-10 features two analog inputs, a single-ended RCA input and a balanced XLR input, while the headphone outputs on the front include single-ended 6.35mm jack, balanced 4.4mm jack and balanced 4-pin XLR.

HIFIMAN GA-10: High-performance tube headphone amplifier

At the heart of the GA-10 are no fewer than 4 ECC83/12AX7 and 4 EL84 tubes. The combination of these tubes in a SEPP (Single-Ended Push-Pull) architecture delivers a sound with natural analog warmth, while keeping noise and distortion levels to a minimum. It has an output power of up to 600mW at 32 ohms. On the performance side, it offers a slightly extended frequency response from 20Hz to 24kHz and a THD+N of just 0.001%. It therefore rivals some very high-end headphone amplifiers.

Photo of GA-10 components

HIFIMAN GA-10: An optimized power supply

The HiFiMAN GA-10's power supply incorporates a transformer of no less than 120W for a substantial power reserve. This transformer is also efficiently isolated and shielded to limit EMI/RFI interference. Voltage regulators and capacitors complete the package within the GA-10's SEPP architecture.

HiFiMAN GA-10 overview

HiFiMAN GA-10 overview
1ON/OFF switch
2Balanced XLR 4-pin headphone output
3Single-ended 6.35mm jack headphone output
4Balanced 4.4mm jack headphone output
5Volume
6Gain adjustment
7Input selector
8Balanced XLR analog input
8Single-ended RCA analog input

Technical characteristics

Specifications
Product typeHeadphone amplifier
Preamplifier stageECC83/12AX7 tubes
Power satgeEL84 tubes
Inputs1x Single-ended RCA input
1x Balanced XLR input
Outputs1x Single-ended 6.35mm jack headphone output
1x Balanced 4.4mm jack headphone output
1x Balanced XLR 4-pin headphone output
Frequency response20Hz-24kHz +/-5dB @ 1kHz
THD+N0.001% @ 1kHz @ 300 ohm
Output power600mW @ 32 ohm (1kHz)
3000mW @ 300 ohm
General
Power supply220V AC 50/60Hz
Power consumption70W
ColorBlack
Dimensions330 x 380 x 110mm
Package1x HiFiMAN GA-10
1x Power supply cable

Data sheet
InputXLR
InputRCA
OutputJack 4.4mm
OutputJack 6.35mm
OutputXLR
ColorBlack
ClassTube amp
Remote ControlNo
