SMSL SA-160 Amplifier TDA7498E 2x 100W 4 Ohm / Headphone Amplifier Gold

Here is the SMSL SA-160, a Class D amplifier architectured around a TDA7498E delivering 2x 100W. It also incorporates a headphone amplifier capable of providing 130mW under 32 Ohm.
It is designed from high-end components such as Elna capacitors, Nichicon, ALPS potentiometer, EPCOS filter, etc.
It is a powerful and robust amplifier whose entire chassis is made of Aluminum.

The design and finishes are neat (CNC machining), its ergonomics is an indisputable advantage.
Its technical characteristics are a significant advantage compared to the competitors of this range: it is efficient and precise.

Characteristics :

• Amplifier TDA7498E
• Frequency response: 20Hz - 20kHz to +/- 3dB
• Noise Ratio: 98dB
• THD: 0.01%
• Output Power: 2x 100W Under 4 Ohms
• Input Level: 400mV - 2V
• Headphone output power: 130mW (under 32 Ohms)
• THD = N: <0.009%
• Adjusting volume
• EMI Filtering
• Short circuit protection
• Protection against overheating
• RCA Stereo Input
• Headphones Jack 3.5mm
• Output Hp terminal blocks accepting banana plugs
• Chassis Anodized Aluminum Black
• Dimensions: 168x98x36mm
• Weight: 1.5kg
• Color: Gold (Champagne)
• Power Supply 36V DC 5.7A included
