DAYTON AUDIO DTA30HP Class D Amplifier TPA3116D2 2x15W 4 Ohm
The highly effective amplification of the Dayton Audio DTA30HP unveils an incredible scene and sound presence, as well as great clarity and precision. It integrates an amplifier chip TPA3116D2 capable of delivering a power of 2x15W under 4Ω with a high efficiency of 90%.
By buying this product you get 6 loyalty points
Reference : 14169
New product
Accessories for this product
Find here a selection of useful and/or essential accessories for this product. These are specially selected by the Audiophonics team according to the characteristics of the product.
Dayton Audio DTA30HP
Amplificateur Class D TPA3116D2 2x15W 5 Ohm
The highly effective amplification of the Dayton Audio DTA30HP unveils an incredible scene and sound presence, as well as great clarity and precision. It integrates an amplifier chip TPA3116D2 capable of delivering a power of 2x15W under 4Ω with a high efficiency of 90%. This chip also has thermal protection and short-circuit protection.
The headphone amplification section is provided by a TPA6110A2 chip capable of delivering 150mW per channel continuously, with a 16Ω headphone.
On the connector side, nothing could be easier, the DTA30HP offers a stereo RCA input and a 3.5mm jack input as well as a 6.35mm jack headphone output and a speaker output on screw terminals.
Caution, the power supply delivered with the product is a US power supply. You need this accessory to use it in France : 2-pin USA power adapter to FR plug.
Technical characteristics
| Specifications | |
|---|---|
| Product type | Amplifier Headphone amplifier |
| Amplification chip | TPA3116D2 |
| Headphone amplification chip | TPA6110A2 |
| Power | 2x15W @ 4Ω |
| Headphone output power | 10mW |
| Minimum speaker impedance | 4Ω |
| Frequency response | 20Hz - 20kHz |
| THD | < 0.1% @ 1WPC |
| SNR | 96dB (A-Weighted) |
| Inputs | 1x Stereo RCA 1x Jack 3.5mm |
| Outputs | Speaker terminals 1x Jack 6.35mm headphone output |
| Input impedance | 10kΩ |
| Input sensitivity | 470mV |
| Channel separation | 77dB |
| Efficiency | > 90% |
| Dynamic range | > 100dB |
| General | |
|---|---|
| Supply voltage | 12V DC 2A |
| Weight | 590g |
| Dimensions | 97 x 131 x 32mm |
| Housing material | Aluminium |
| Color | Black |
| Input | RCA |
| Input | Jack 3.5mm |
| Output | Speaker terminal |
| Output | Jack 6.35mm |
| Color | Black |
| Channel | 2 (Stereo) |
| Class | Class D / T |
| Amplifier chip | TPA6110A2 |
| Amplifier chip | TPA3116 |
| Power (W) | 30.0 |
