This compact, versatile and high-performance O-Noorus PA-98E Class D amplifier uses a TDA7498E amplifier chip and is thus capable of delivering a comfortable 2x125W power output at 4Ω (1% THD). Practical, it incorporates a single-ended stereo RCA input, a USB-A port and also a Bluetooth 5.0 receiver for wireless music streaming from a smartphone, for example. Outputs include speaker terminals and a subwoofer output (RCA) for setting up a 2.1 audio system. The front panel features a volume control knob, associated with an NJW1194 controller, as well as two gain control knobs for bass and treble (+/-10dB). All components are housed in a sturdy, sober CNC-machined aluminum case.
Technical characteristics
Specifications | |
---|---|
Product type | Amplifier |
Amplification type | Class D |
Amplification chip | TDA7498E |
Inputs | Bluetooth 5.0 1* Single-ended stereo RCA 1* USB-A |
Outputs | Speaker terminals 1* Subwoofer output (RCA) |
Output power | 2x125W @ 4Ω, 1% THD |
Frequency response | 10Hz - 30kHz |
Input sensitivity | 200mV |
THD+N | 0.34% |
THD | 0.357% |
SNR | 90.974dB |
General | |
---|---|
Supply voltage | 36VDC (power supply included) |
PCB dimensions | 145*136*40mm |
Weight | 680g |
Housing material | Aluminium |
Color | Black |
Package | 1* O-Noorus PA-98E 1* Power supply 1* Antenna 1* USB-A cable |
Input | USB |
Input | Bluetooth |
Input | RCA |
Output | Speaker terminal |
Output | Subwoofer |
Color | Black |
Channel | 2.1 |
Channel | 2 (Stereo) |
Class | Class D / T |
Amplifier chip | TDA7498E |
Power (W) | 125.0 |
Remote Control | No |
