Jantzen Audio Silver Z-Cap 001-0606 Capacitor 0.15µF 1200V
The Jantzen Audio Silver Z-Cap capacitors allow perfect sound neutrality and tonal balance to be maintained. They are particularly suitable for use with a tweeter or midrange in passive high-end loudspeakers, but also as coupling capacitors in an amplifier.
All Silver Z-Cap capacitors are nitrogen-filled, giving more foil per capacitor and no risk of evaporation. The wires are made of silver for maximum conductivity.
Technical characteristics
| Specifications | |
|---|---|
| Product type | Non-polarised Super MKP capacitor |
| Capacitance | 0.15µF |
| DC voltage | 1200V |
| AC voltage | 800V |
| Tolerance | ±2% |
| Construction | Dual foil |
| Format | Axial |
| Electrode | Vacuum-deposited aluminium coating |
| Wires material | Silver |
| Dielectric absorption factor | < 0.5% @ 20°C |
| Dielectric thickness | PB=6µm |
| Self induction | 0mH |
| Insulation resistance | < 100000MΩ @ 20°C |
| Temperature range | -55°C / +85°C |
| Metal layer thickness | PB=0.4µm |
| Metal layer conductivity | PB=2.5Ω/cm² |
| Dimensions & Weight | |
|---|---|
| Diameter | 17mm |
| Length | 43mm |
| Weight | 15g |
| Tolerance (%) | 2 |
| Capacitor capacitance (µF) | 0.15 |
| Rated voltage (V) | 1200 |
| Capacitor type | Film capacitor |
| Capacitor format | Axial |
