JANTZEN AUDIO SILVER Z-CAP 001-0616 Capacitor 1200V 0.39µF
By buying this product you get 1 loyalty point
![[GRADE S] FURUTECH DAS-4.1 Balanced Interconnect Cable OCC DUCC Copper Ø10mm 1.3m](https://www.audiophonics.fr/64493-thumb_default/furutech-das-41-balanced-interconnect-cable-occ-ducc-copper-o10mm.jpg)
![[GRADE A] AUNE S9C PRO DAC 2x ES9068AS Discreet Headphone Amplifier 5W Bluetooth 32bit 768kHz DSD512 MQA Back](https://www.audiophonics.fr/64487-thumb_default/aune-s9c-pro-dac-2x-es9068as-discreet-headphone-amplifier-5w-bluetooth-32bit-768khz-dsd512-mqa-back.jpg)
![[GRADE A] Mono Power Amplifier Modules LM3886 with Heatsinks 2x120W / 8 Ohm (Pair)](https://www.audiophonics.fr/64212-thumb_default/mono-power-amplifier-modules-lm3886-2x120w-8-ohm-pair.jpg)
![[GRADE S] IAN CANADA STATIONPI SMT Raspberry Pi and HAT Boards Adapter Station](https://www.audiophonics.fr/64200-thumb_default/ian-canada-stationpi-smt-raspberry-pi-adapter.jpg)
Jantzen Audio Silver Z-Cap 001-0616 Capacitor 0.39µF 1200V
The Jantzen Audio Silver Z-Cap capacitors allow perfect sound neutrality and tonal balance to be maintained. They are particularly suitable for use with a tweeter or midrange in passive high-end loudspeakers, but also as coupling capacitors in an amplifier.
All Silver Z-Cap capacitors are nitrogen-filled, giving more foil per capacitor and no risk of evaporation. The wires are made of silver for maximum conductivity.
Technical characteristics
| Specifications | |
|---|---|
| Product type | Non-polarised Super MKP capacitor |
| Capacitance | 0.39µF |
| DC voltage | 1200V |
| AC voltage | 800V |
| Tolerance | ±2% |
| Construction | Dual foil |
| Format | Axial |
| Electrode | Vacuum-deposited aluminium coating |
| Wires material | Silver |
| Dielectric absorption factor | < 0.5% @ 20°C |
| Dielectric thickness | PB=6µm |
| Self induction | 0mH |
| Insulation resistance | < 100000MΩ @ 20°C |
| Temperature range | -55°C / +85°C |
| Metal layer thickness | PB=0.4µm |
| Metal layer conductivity | PB=2.5Ω/cm² |
| Dimensions & Weight | |
|---|---|
| Diameter | 31mm |
| Length | 45mm |
| Weight | 26g |
| Tolerance (%) | 2 |
| Capacitor capacitance (µF) | 0.39 |
| Rated voltage (V) | 1200 |
| Capacitor type | Film capacitor |
| Capacitor format | Axial |
