JANTZEN AUDIO SILVER Z-CAP Capacitor 800V 0.68µF

Jantzen Audio Silver Z-Cap capacitors maintain perfect sound neutrality and a very nice tonal balance. They are particularly suitable for use with a tweeter or midrange in passive high-end loudspeakers, but also as a coupling capacitor in an amplifier.
No customer reviews yet, login to write a review.

By buying this product you get 1 loyalty point


Reference : 10018
New product

17,90 €tax incl.

14,92 € tax excl.

- +


Shipping date: 24-12-2024.

Orders placed before 12h (GMT+1) will generally be shipped the same day (working day).

Livraions depuis la france

Livraison depuis la france Livraison depuis la france Livraison depuis la france

Livraison depuis la France
Facturation France
SAV France

2 Years warranty

More info

Jantzen Audio Silver Z-Cap

Capacitor 800V 0.68µF

Jantzen Audio Silver Z-Cap Condensateur

Jantzen Audio Silver Z-Cap capacitors maintain perfect sound neutrality and a very nice tonal balance. They are particularly suitable for use with a tweeter or midrange in passive high-end loudspeakers, but also as a coupling capacitor in an amplifier.

All Silver Z-Cap condensers are filled with nitrogen, allowing more sheets per condenser and no risk of evaporation. The wires are made of Silver for maximum conductivity.

Technical characteristics

Specifications
Product typeCapacitor (Non-Polarized Super MKP)
Capacity0.68µF
Voltage800VDC
Tolerance±2%
ConstructionDual foil
Axial
ElectrodeAluminum metallized, vacuum deposited
Wires materialSilver
Dielectric absorption factor< 0.5% @ 20°C
Dielectric thicknessPB=6µm
Self-Inductance0nH
Insulation resistance< 100000MΩ @ 20°C
Temperature range-55°C to +85°C
Metal layer thicknessPB=0.4µm
Metal layer conductivityPB=2.5Ω/cm²
General
DimensionsØ16 x 43mm
Weight13.6g

Data sheet
Tolerance (%)2
Capacitor capacitance (µF)0.068
Rated voltage (V)800
Capacitor typeFilm capacitor
Capacitor formatAxial
