JANTZEN AUDIO SILVER Z-CAP Capacitor 800V 1μF

Jantzen Audio Silver Z-Cap capacitors maintain perfect sound neutrality and a very nice tonal balance. They are particularly suitable for use with a tweeter or midrange in passive high-end loudspeakers, but also as a coupling capacitor in an amplifier.
Average votes for this product
5.0 / 5

By buying this product you get 1 loyalty point


Reference : 6607
New product

18,50 €tax incl.

15,42 € tax excl.

- +


Shipping date: 04-12-2024.

Orders placed before 12h (GMT+1) will generally be shipped the same day (working day).

Livraions depuis la france

Livraison depuis la france Livraison depuis la france Livraison depuis la france

Livraison depuis la France
Facturation France
SAV France

2 Years warranty

More info

Jantzen Audio Silver Z-Cap

Capacitor 800V 1µF

Jantzen Audio Silver Z-Cap Condensateur

Jantzen Audio Silver Z-Cap capacitors maintain perfect sound neutrality and a very nice tonal balance. They are particularly suitable for use with a tweeter or midrange in passive high-end loudspeakers, but also as a coupling capacitor in an amplifier.

All Silver Z-Cap condensers are filled with nitrogen, allowing more sheets per condenser and no risk of evaporation. The wires are made of Silver for maximum conductivity.

Technical characteristics

Specifications
Product typeCapacitor (Non-Polarized Super MKP)
Capacity1µF
Voltage800VDC
Tolerance±2%
ConstructionDual foil
Axial
ElectrodeAluminum metallized, vacuum deposited
Wires materialSilver
Dielectric absorption factor< 0.5% @ 20°C
Dielectric thicknessPB=6µm
Self-Inductance0nH
Insulation resistance< 100000MΩ @ 20°C
Temperature range-55°C to +85°C
Metal layer thicknessPB=0.4µm
Metal layer conductivityPB=2.5Ω/cm²
General
DimensionsØ18 x 43mm
Weight17g

Data sheet
Tolerance (%)2
Capacitor capacitance (µF)1
Rated voltage (V)800
Capacitor typeFilm capacitor
Capacitor formatAxial

Delivery

We deliver all over France, and internationally.
To find out the amount of shipping costs, simply go to your cart once you have added the desired products.
To discover our different services and delivery options, click on the following logos :

Only registered users can post a review. Log in or create an account .
Average votes
5.0 / 5
2 reviews
Why write products reviews ?
You can share your feelings about products and help other people by sharing your experience

Note :
 5/5
Date :
Parfait
J'ai fait le choix de ce condensateur sans vraiment connaitre la marque JANTZEN. Je connais déjà très bien les MUNDORF Mcap Suprême. Histoire de découvrir autre chose, le but était de remplacer des condensateurs ANSAR (déjà reconnu dans le domaine audio).
Après mise en place des JANTZEN en condensateur de "Liaison" sur la sortie de mon préampli à Tube 6SN7.
(Je rejoins les commentaires de Mr Simon C.) Un son transparent et très détaillé. C'est le résultat d'une longue écoute, et dans différents styles de musique.
Même si l'on monte un peut plus haut dans les fréquences, cela ne me dérange pas, au contraire........
Ces "Condos" sont vraiment excellents.
 (0)
 (0)
This review has been posted for JANTZEN AUDIO SILVER Z-CAP Capacitor 800V 1μF
Note :
 5/5
Date :
Superb capacitor, but...
This is a superbly transparent and detailed capacitor for the cost. It gives far superior resolution compared with low cost metallized film capacitors. I have successfully used this range of Jantzen capacitors both in passive crossovers, and as amplifier decoupling caps.
BUT: there is a slight emphasis at high frequencies, which in a bright sounding system might prove fatiguing. So if you have a neutral or slightly ‘dark’ system, the Jantzen Silver Z-Cap is an excellent choice.
 (2)
 (0)
This review has been posted for JANTZEN AUDIO SILVER Z-CAP Capacitor 800V 1μF
