Capacitor 800V 2.7µF
Jantzen Audio Silver Z-Cap capacitors maintain perfect sound neutrality and a very nice tonal balance. They are particularly suitable for use with a tweeter or midrange in passive high-end loudspeakers, but also as a coupling capacitor in an amplifier.
All Silver Z-Cap condensers are filled with nitrogen, allowing more sheets per condenser and no risk of evaporation. The wires are made of Silver for maximum conductivity.
Specifications | |
---|---|
Product type | Capacitor (Non-Polarized Super MKP) |
Capacity | 2.7µF |
Voltage | 800VDC |
Tolerance | ±2% |
Construction | Dual foil Axial |
Electrode | Aluminum metallized, vacuum deposited |
Wires material | Silver |
Dielectric absorption factor | < 0.5% @ 20°C |
Dielectric thickness | PB=6µm |
Self-Inductance | 0nH |
Insulation resistance | < 100000MΩ @ 20°C |
Temperature range | -55°C to +85°C |
Metal layer thickness | PB=0.4µm |
Metal layer conductivity | PB=2.5Ω/cm² |
General | |
---|---|
Dimensions | Ø30 x 45mm |
Weight | 38g |
Tolerance (%) | 2 |
Capacitor capacitance (µF) | 2.7 |
Rated voltage (V) | 800 |
Capacitor type | Film capacitor |
Capacitor format | Axial |
