KR AUDIO 5U4G Rectifier Tube (Unit)
The KR Audio 5U4G rectifier tube is a high-end thermionic full-wave tube. Its superior design ensures long life and rich, detailed sound.
No customer reviews yet, login to write a review.
By buying this product you get 53 loyalty points
Reference : 19087
New product
Viewed products
![[GRADE S] FURUTECH DAS-4.1 Balanced Interconnect Cable OCC DUCC Copper Ø10mm 1.3m](https://www.audiophonics.fr/64493-thumb_default/furutech-das-41-balanced-interconnect-cable-occ-ducc-copper-o10mm.jpg)
![[GRADE A] AUNE S9C PRO DAC 2x ES9068AS Discreet Headphone Amplifier 5W Bluetooth 32bit 768kHz DSD512 MQA Back](https://www.audiophonics.fr/64487-thumb_default/aune-s9c-pro-dac-2x-es9068as-discreet-headphone-amplifier-5w-bluetooth-32bit-768khz-dsd512-mqa-back.jpg)
![[GRADE A] Mono Power Amplifier Modules LM3886 with Heatsinks 2x120W / 8 Ohm (Pair)](https://www.audiophonics.fr/64212-thumb_default/mono-power-amplifier-modules-lm3886-2x120w-8-ohm-pair.jpg)
![[GRADE S] IAN CANADA STATIONPI SMT Raspberry Pi and HAT Boards Adapter Station](https://www.audiophonics.fr/64200-thumb_default/ian-canada-stationpi-smt-raspberry-pi-adapter.jpg)
KR AUDIO 5U4G Rectifier Tube (Unit)
The KR Audio 5U4G rectifier tube is a high-end full-wave thermionic tube. This tube offers excellent performance in terms of current rectification, thanks to its ability to deliver a stable, regular voltage. Its superior design ensures long life and rich, detailed sound.
Technical characteristics
| Specifications | |
|---|---|
| Product type | Rectifier tube |
| Tube type | Full-wave thermionic tube |
| AC voltage | 5V |
| AC current | 3A |
| MAXIMUM VALUES (WITH CHOKE-INPUT FILTER) | |
|---|---|
| AC plate voltage per plate (RMS) | 550V |
| DC output current | 225mA |
| Minimum input-choke inductance | 3 henrys |
| MAXIMUM VALUES (with capacitor input filter) | |
|---|---|
| AC-plate voltage per plate (RMS) | 450V |
| DC output current | 225mA |
| Min. Total Eff. Plate-supply impedance per plate | 75 ohms |
| Input capacitor should not exceed 10 micro farads | |
| General | |
|---|---|
| Package | 1x KR AUDIO 5U4G rectifier tube |
