TOPPING NX4S USB DAC battery Headphone Amplifier ES9038Q2M 32bit/768Khz Noir

The NX4S Topping is the ideal solution, both easy to use and extremely effective, to offer your headphones a whole new dimension. It pushes the limits, exceeding the characteristics required for High Definition Hi-Res files with a bandwidth of 20Hz - 100kHz.

Average votes for this product
5.0 / 5

By buying this product you get 15 loyalty points


Reference : 12549
New product

159,00 €tax incl.

132,50 € tax excl.
Including 0,01 € for green tax

This product is discontinued
Livraions depuis la france

Livraison depuis la france Livraison depuis la france Livraison depuis la france

Livraison depuis la France
Facturation France
SAV France

2 Years warranty

More info

Topping NX4DSD

USB DAC battery Headphone Amplifier ES9038Q2M 32bit/768Khz Noir

Topping NX4DSD DAC USB Amplificateur Casque sur Batterie ES9038Q2M 32bit 768kHz Noir

Simple & Efficient

The NX4S Topping is the ideal solution, both easy to use and extremely effective, to offer your headphones a whole new dimension. It pushes the limits, exceeding the characteristics required for High Definition Hi-Res files with a bandwidth of 20Hz - 100kHz. This USB OTG 32bit 384kHz OTG 32bit 384kHz DSD512 Native nomadic DAC is thus an ideal client for its thinness and compactness, providing a converter is a high quality headphone amplification for Android and iOS smartphones. (depending on the model and operating system).

Topping NX4DSD DAC USB Amplificateur Casque sur Batterie ES9038Q2M 32bit 768kHz Noir

Components of the highest quality

Das NX4S DSD verfügt über die Referenzen des Marktes in Bezug auf Komponenten, die darauf ausgelegt sind, Ihnen eine optimale, Hi-Res-zertifizierte Leistung zu bieten. Die hochwertige Schaltung beinhaltet eine XMOS U208 USB-Schnittstelle mit drei separaten Clocks, einen ES9038Q2M DAC und die neueste Generation der TI OPA2140 Operationsverstärker. Diese Architektur ermöglicht es, PCm-Abtastraten bis zu 32bit 768kHz und DSD512 bis zu nativen DSD zu unterstützen. Darüber hinaus bietet es einen SNR von 119 dB und einen THD+N von nur 0,0008% im USB-DAC-Modus.

Topping NX4DSD DAC USB Amplificateur Casque sur Batterie ES9038Q2M 32bit 768kHz Noir

An autonomy adapted to your mobile uses

USB DAC battery Headphone Amplifier ES9038Q2M 32bit768Khz BlackThe Topping NX4 DSD includes a large battery allowing it to have an extended battery life for long listening sessions, whether in mobile mode with a smartphone or in sedentary mode using the DAC function. Thus, its autonomy is 28 hours in playback mode in headphone amplifier mode and 7h30 in USB DAC mode + headphone amplifier. LED indicators indicate when it is necessary to charge the NX4 DSD.

Topping NX4DSD DAC USB Amplificateur Casque sur Batterie ES9038Q2M 32bit 768kHz Noir
Topping NX4DSD DAC USB Amplificateur Casque sur Batterie ES9038Q2M 32bit 768kHz NoirTopping NX4DSD DAC USB Amplificateur Casque sur Batterie ES9038Q2M 32bit 768kHz Noir

Topping NX4 DSD Review by Audio Science Review

The Topping NX4 DSD is a superb portable DAC and headphone offering at super attractive pricing. The DSD NX4 has impressed me greatly. It would be my choice for a portable headphone+DAC or a stand-alone desktop DAC for that matter. "
Test du Topping NX4 DSD par Audio Science Review

Technical characteristics

Specifications
Product typeDAC and Headphone Amplifier
Inputs1x Jack 3.5mm
1x Micro USB OTG
Output1x Jack 3.5mm
Frequency response20Hz - 100kHz +/-2dB
Max output power293mW @ 32Ω, 114mW @ 300Ω
SNR119dB @ 1kHz
THD0.0008% @ 1kHz
Acceptable headphone impedances16-300Ω
Input sensitivity1.8Vrms
Noise< 2µV @ 32Ω
Gain5.6dB
Battery capacity2400mAh (temps de chargement 4h)
Supported sampling ratesPCM up to 32bit 768kHz
DSD up to DSD512 natif
Crosstalk-96dB @ -1kHz
Switchable gain0dB / 8.8dB
General
Dimensions11 x 6.8 x 1.4cm
ColorBlack
Case materialAluminium
Weight148g
LoadVia Micro USB
Accessories1x Audio Cable 3.5m
1x Micro USB Cable
1x USB-C Cable
1x USB Charger
2x Silicon strips
5x Velcros
1x User guide

Data sheet
InputUSB
InputJack 3.5mm
OutputJack 3.5mm
ColorBlack
Remote ControlNo
