MUNDORF MCAP EVO OIL Capacitor 450V 8.2μF

Average votes for this product
4.0 / 5

By buying this product you get 1 loyalty point


Reference : 7299
New product

19,90 €tax incl.

16,58 € tax excl.

- +


Shipping date: 24-12-2024.

Orders placed before 12h (GMT+1) will generally be shipped the same day (working day).

Livraions depuis la france

Livraison depuis la france Livraison depuis la france Livraison depuis la france

Livraison depuis la France
Facturation France
SAV France

2 Years warranty

More info
Condensateur MUNDORF MCAP EVO OIL Condensateur 450V 8.2µF

Mundorf MCAP EVO Oil

The EVO series at Mundorf is intended to offer very high audio precision at a low price and with minimal space-use
Its polypropylene film (PP) is metallized with a layer of aluminum as thick as possible and with a proprietary geometry (Evolution Winding). The coil is then hand-mounted in a shell designed to reduce vibrations.

All these features contribute to a very lively audio reproduction that deeply respects microdynamics and stereophony. The whole EVO series is compliant to the highest standards of safety (self-healing).

Rigid wires for connections are long enough to allow vertical or horizontal mounting. Note that the shorter tab indicates the outer sheet of the capacitor.

This model belongs to the EVO Oil range introducing an oil impregnation step of the polypropylene (PP) films before building the coil. This maneuver removes residual air bubbles with formidable efficiency, which drastically reduces the electrical and mechanical losses associated with vibrations.

Dimensions

Capacitor Mcap EVO
Specifications
TypeCapacitor Mcap EVO
Capacitance8,20 µF
Voltage450V
Tolerance±3%
Diameter35
Lengthr27
Connct wire diameter1,0
Connect wire length (A)35
Connect wire length (B)60
Maximum room temp85°C
DielectricPolypropylene (PP)
MetallisationAluminum
Dielectric loss0.0002@1kHz · 0.0001@10kHz

Data sheet
Tolerance (%)3
Capacitor capacitance (µF)8.2
Rated voltage (V)450.0
Capacitor typeFilm capacitor
Capacitor formatAxial

Delivery

We deliver all over France, and internationally.
To find out the amount of shipping costs, simply go to your cart once you have added the desired products.
To discover our different services and delivery options, click on the following logos :

Only registered users can post a review. Log in or create an account .
Average votes
4.0 / 5
1 reviews
Why write products reviews ?
You can share your feelings about products and help other people by sharing your experience

Note :
 4/5
Date :
Bon condensateur
Monté en parallèle sur un tweeter je n'ai pas entendu de difference avec un Mcap supreme. Monté en direct sur un tweeter c'et moins bon que le Mcap supreme ou le jantzen superior Zcap , le piano ne passe pas vraiment, c'est bon sur les voix,. Beaucoup mieux que le Mcap standard: moins de dureté , Montage 50% Evo Oil et 50% Mcap supreme en direct sur un medium cela donne un bon resultat et gomme le coté un peu analityque du Mcap supreme
 (1)
 (0)
This review has been posted for MUNDORF MCAP EVO OIL Capacitor 450V 8.2μF
