MUNDORF MCAP EVO SILVERGOLD OIL Capacitor 450V 0.22μF

Mundorf MCAP EVO SilverGold Oil

EVO Mcap by Mundorf is designed to ofeer tremendous audio precision at affordable price with low space-consumption. It fills every condition to offer a great sound restitution with rich and deep audio details.
Its polypropylene film (PP) is metallized with a layer of aluminum as thick as possible and formed following a proprietary geometry (Evolution Winding). The coil is then hand-poted in a audio shell order to reduce vibrations.

All these features contribute to a very lively audio reproduction that deeply respects microdynamics and stereophony. The whole EVO series is compliant to the highest standards of safety (self-healing).

Rigid wires for connections are made from gold-plated copper. They are long enough to allow vertical or horizontal mounting. Note that the shorter tab indicates the outer sheet of the capacitor.

This model belongs to the EVO Oil range introducing an oil impregnation step of the polypropylene (PP) films before building the coil. This maneuver removes residual air bubbles with formidable efficiency, which drastically reduces the electrical and mechanical losses associated with vibrations.
