MUNDORF MCAP SUPREME EVO OIL Capacitor 15µF
Viewed products
Mundorf Mcap Supreme EVO Oil capacitor
The Mcap Supreme EVO Oil serie by Mundorf uses the EVO winding method which takes advantage of two non-symetric axis for a better precision and great dynamics (upgraded pulse response). It also benefits from the technological Mcap Supreme build which removes residual inductance and promotes a tremendously realistic audio scene.
The structure of the condenser is treated with aluminum oil, a very effective solution to prevent the formation of air bubbles during construction and to dissipate any excess heat to ensure optimum operating conditions.
It combines the EVO capacitor precision with the famed 'liquid sound' from Mcap Supreme.
This reference is ideal for building, designing, repairing or upgrading any high-quality speaker system. It will provide best result with Accuton, SEAS, Scanspeak Revelator, Morel, JBL PRO, TAD.
Dimensions
All units are mm
| Specifications | |
|---|---|
| Capacity | 15µf |
| Dielectrics | Polypropylene (PP). |
| Aluminium metalization | 99,99%. |
| Dlielectric losses | 0,0002 à 1 kHz, 0,0001 à 10 kHz. |
| Max temperature | 85°C. |
| Tension | 800V |
| Tolerance | +/- 2% |
| Diameter (body) | ⌀76 mm |
| Length (body) | 51 mm |
| Diameter (wires) | ⌀1.4mm |
| Length (wires) | Long : 95 mm Short : 50 mm |
| Tolerance (%) | 2 |
| Capacitor capacitance (µF) | 15 |
| Rated voltage (V) | 800 |
| Capacitor type | Film capacitor |
| Capacitor format | Axial |
