MUNDORF BL140 Air Core Self 1.4mm 1mH

Air coils, for physical reasons, are unbeatable in terms of precision on the restitution of the impulses, and are free of any distortion (contrary to ferrite coils). For this reason, Mundorf produces coils with a large wire diameter for purists. It is therefore possible to achieve better inductances while maintaining low internal impedance and zero distortion.

Average votes for this product
5.0 / 5

By buying this product you get 3 loyalty points


Reference : 4207
New product

31,90 €tax incl.

26,58 € tax excl.

- +


Shipping date: 27-12-2024.

Orders placed before 12h (GMT+1) will generally be shipped the same day (working day).

Livraions depuis la france

Livraison depuis la france Livraison depuis la france Livraison depuis la france

Livraison depuis la France
Facturation France
SAV France

2 Years warranty

More info

Mundorf BL140

Air Core Self 1.4mm 1mH

Mundorf BL140 Self à air 1.4mm

Air coils, for physical reasons, are unbeatable in terms of precision on the restitution of the impulses, and are free of any distortion (contrary to ferrite coils). For this reason, Mundorf produces coils with a large wire diameter for purists. It is therefore possible to achieve better inductances while maintaining low internal impedance and zero distortion.

Baked varnished coil

When an electric current passes through a coil it causes the different windings to vibrate. The microphonic effect (conversion of a mechanical movement into electrical oscillations) adds these oscillations to the original musical signal. The varnished coils are made from a special wire. An extra layer of varnish on the outside of the wire is melted quickly by the passage of a strong electrical impulse. After this process, the coils are glued together and can therefore no longer emit vibrations.

Mundorf BL140 Self à air 1.4mm

Technical characteristics

Specifications
Product typeAir core coil
Inductivity1mH
DC Resistance0.28Ω
Section1.54mm² (15AWG)
Wire diameterØ1.4mm
ConductorOFC Copper
DimensionsØ58 x 28mm

Data sheet
Inductance (mh)1.0

Delivery

We deliver all over France, and internationally.
To find out the amount of shipping costs, simply go to your cart once you have added the desired products.
To discover our different services and delivery options, click on the following logos :

Only registered users can post a review. Log in or create an account .
Average votes
5.0 / 5
1 reviews
Why write products reviews ?
You can share your feelings about products and help other people by sharing your experience

Note :
 5/5
Date :
Un classique
Les bobines Mundorf sont un grand classique. Je favorise à chaque fois que je le peux, la version "BL" qui est la version "vernie" de la "L". Moins de vibration et seulement quelques euros de plus.
