Capacitor 40V 6800µF
These capacitors have been specially developed for small power amplifiers or preamplifiers. This new product replaces the M-Lytic SI series. The "Glue-On" output pins made of tinned Copper with a diameter of 1.2mm allow compatibility with most "Snap In" capacitors.
| Specifications | |
|---|---|
| Product type | Capacitor |
| Capacity | 6800µF |
| Voltage | 40VDC |
| Tolerance | ±20 |
| Rated Ripple Current IR @ TMax, 100Hz | 2.1A |
| Surge voltage | 46VDC |
| ESR @ 100Hz | 42mΩ |
| ESL | 20nH |
| Maximal reverse voltage | 2V |
| Loss factor (tan ∂ @ 100Hz) | 18 |
| Nominal current IR for 5min | 1632µA |
| Useful lifetime | 3000h @ +125°C 8000h @ +105°C 16000h @ +85°C |
| Temperature range | -40°C to 125°C |
| RoHS | |
| Général | |
|---|---|
| Dimensions | Ø25 x 35mm |
| Diamètre fils | 1.2mm |
| Longueur des fils | 9mm |
| Espacement des fils | 10mm |
| Tolerance (%) | 20 |
| Capacitor capacitance (µF) | 6800 |
| Rated voltage (V) | 40.0 |
| Capacitor type | Electrolytic capacitor |
| Capacitor format | new |
