Capacitor 1000V 3.9µF
The metallization of the MCap Supreme SilverGold capacitor foil is composed of pure Silver mixed with 1% very pure Gold. Gold modifies the crystal structure of silver and maximizes its excellent electrical conductivity. The outstanding characteristics of the MCap Supreme - richness of detail and spatial quality of the music reproduced, are once again audibly optimized and the use of silver and gold enriches them with a wide range of finely nuanced acoustic timbres.
Careful quality controls before, during and after the demanding manufacturing process guarantee the user extremely tight tolerances and long-term stability which is extremely high. To avoid possible oscillations that would distort the musical signal. This capacitor is further mechanically stabilized in a special process. The minimal tolerances of the components used in the signal path form the decisive basis for realistic, stereophonic and three-dimensional reproduction. Exact identification of musicians and a corresponding three-dimensional representation are only possible if the characteristics of the left and right channels are identical.
The technical precision and speed of the MCap Supreme SilverGold harmonizes perfectly with the beauty and elegance of the music from absolute silence. All the lively variety, clarity and strength of instruments and voices blossom into a wonderfully transparent spatiality.
This SilverGold Oil version represents the top of the range, thanks to its oil impregnation. It thus allows a better sound reproduction with improved presence and dynamics.
Specifications | |
---|---|
Product type | Capacitor |
Capacity | 3.9µF |
Voltage | 1000V |
Tolerance | ±2% |
Dielectric | Polypropylene (PP) |
Metallization | Silver 99% + Gold 1% |
Impregnation | Oil |
Loss factor | tan ∂ 0.0002 @ 1kHz tan ∂ 0.0001 @ 10kHz |
Max ambient temperature | 85°C |
General | |
---|---|
Dimensions | Ø41 x 57mm |
Wires diameter | 1mm |
Wires length | 60mm |
Tolerance (%) | 2 |
Capacitor capacitance (µF) | 3.9 |
Rated voltage (V) | 1000.0 |
Capacitor type | Film capacitor |
Capacitor format | Axial |
