NICHICON FG Audio Electrolytic Capacitor 35V 470µF
This Aluminium Nichicon electrolytic capacitor has a nominal voltage of 35V for a capacity of 470µF. Its tolerance is 20%. It offers excellent performance and is ideal for use in an audio circuit.
No customer reviews yet, login to write a review.
No loyalty points for this product.
Reference : 15157
New product
Viewed products
![[GRADE B] IFI AUDIO IDEFENDER+ Anti Ground Loop Filter Male USB-A to Female USB-A](https://www.audiophonics.fr/65620-thumb_default/ifi-audio-idefender-anti-ground-loop-filter-male-usb-a-to-female-usb-a.jpg)
![[GRADE A] FIIO K11 DAC CS43198 Headphone Amplifier 32bit 384kHz DSD256 Black](https://www.audiophonics.fr/65622-thumb_default/fiio-k11-black.jpg)
![[GRADE A] MATRIX ELEMENT M Streamer DAC ES9028Pro WiFi AirPlay DLNA MQA 32bit 768khz DSD512](https://www.audiophonics.fr/65635-thumb_default/matrix-element-m-streamer-dac-es9028pro-wifi-airplay-dlna-mqa-32bit-768khz-dsd512.jpg)
![[GRADE A] MOONDROP COSMO Planar Magnetic Open-Back Circumaural Headphone Ø100mm 100dB 15 Ohm 13Hz-58kHz](https://www.audiophonics.fr/65641-thumb_default/moondrop-cosmo.jpg)
![[GRADE A] AUDIOPHONICS Power cable shielded OLFLEX 110CY 3x2.5mm² 1.15m](https://www.audiophonics.fr/65644-thumb_default/audiophonics-power-cable-shielded-olflex-110cy-3x25mm-115m.jpg)
NICHICON Fg
Audio Electrolytic Capacitor 35V 470µF
This Aluminium Nichicon electrolytic capacitor has a nominal voltage of 35V for a capacity of 470µF. Its tolerance is 20%. It offers excellent performance and is ideal for use in an audio circuit.
Technical characteristics
| Specifications | |
|---|---|
| Product type | Aluminum electrolytic capacitor (FG Range) |
| Rated voltage | 35VDC |
| Capacitance | 470µF |
| Tolerance | 20% |
| Format | Radial |
| Operating temperature range | -40°C / +85°C |
| Diameter | Ø12.5mm |
| Wires spacing | 5mm |
| Height | 25mm |
| Life cycle | 1000h |
| Ripple current | 590mA |
| Tolerance (%) | 20 |
| Capacitor capacitance (µF) | 470 |
| Capacitor capacitance (µF) | 220 |
| Rated voltage (V) | 25.0 |
| Capacitor type | Electrolytic capacitor |
| Capacitor format | Radial |
