NICHICON KG GOLD TUNE HiFi Audio Capacitor 50V 4700µF
Nichicon electrolytic capacitors from the KG Gold Tune range are specifically designed for high fidelity audio applications. They can be integrated into many devices in your audio system.
No customer reviews yet, login to write a review.
No loyalty points for this product.
Reference : 5572
New product
![[GRADE B] IFI AUDIO IDEFENDER+ Anti Ground Loop Filter Male USB-A to Female USB-A](https://www.audiophonics.fr/65620-thumb_default/ifi-audio-idefender-anti-ground-loop-filter-male-usb-a-to-female-usb-a.jpg)
![[GRADE A] FIIO K11 DAC CS43198 Headphone Amplifier 32bit 384kHz DSD256 Black](https://www.audiophonics.fr/65622-thumb_default/fiio-k11-black.jpg)
![[GRADE A] MATRIX ELEMENT M Streamer DAC ES9028Pro WiFi AirPlay DLNA MQA 32bit 768khz DSD512](https://www.audiophonics.fr/65635-thumb_default/matrix-element-m-streamer-dac-es9028pro-wifi-airplay-dlna-mqa-32bit-768khz-dsd512.jpg)
![[GRADE A] MOONDROP COSMO Planar Magnetic Open-Back Circumaural Headphone Ø100mm 100dB 15 Ohm 13Hz-58kHz](https://www.audiophonics.fr/65641-thumb_default/moondrop-cosmo.jpg)
![[GRADE A] AUDIOPHONICS Power cable shielded OLFLEX 110CY 3x2.5mm² 1.15m](https://www.audiophonics.fr/65644-thumb_default/audiophonics-power-cable-shielded-olflex-110cy-3x25mm-115m.jpg)
Nichicon KG Gold Tune
Electrolytic Capacitor Audio HiFi 50V 4700µF
Nichicon KG series capacitors have been specially designed for audio. Thus, they make it possible to reach a high-fidelity sound reproduction and can be integrated in various devices of your audio system (analog circuit of a DAC, preamplifier or power amplifier input for example...).
This is the model with a voltage of 50V and a capacity of 4700µF.
Technical characteristics
| Specifications | |
|---|---|
| Product type | Aluminum electrolytic capacitor |
| Capacity | 4700µF |
| Voltage | 50V DC |
| Connection type | Snap In |
| Tolerance | 20% |
| Temperature range | -40°C / +85°C |
| RoHS | |
| Ripple | 3.9Arms |
| Loss factor | tan δ 0.22 |
| General | |
|---|---|
| Dimensions | Ø30 x 40mm |
| Contacts spacing | 10mm |
| Tolerance (%) | 20 |
| Capacitor capacitance (µF) | 4700 |
| Rated voltage (V) | 50.0 |
| Capacitor type | Electrolytic capacitor |
| Capacitor format | new |
