ELECAUDIO GP-E3 Braided Monofilament Polyester Sheath 3-6mm White
ELECAUDIO GP-E3
Braided sleeving Polyester Monofilament 03-06mm White
The diameter of these sheaths is adjustable from 3 to 6 mm. When your cable measures 06mm it is necessary to plan a reduction of the length of 20%.
Melting temperature: 255°C
It is possible to superimpose 2 layers of braided sheath, so your cable is even better protected. The larger the diameter of the cable, the more the spaces between the braiding will be visible.
Depending on the diameter of your cable, it is necessary to plan the reduction of the sheath length according to the following table:
| SHEATH LENGTH ACCORDING TO CABLE DIAMETER | |
|---|---|
| Cable diameter | Required sheath length |
| 3mm | 1m |
| 4mm | 1.04m |
| 5mm | 1.08m |
| 6mm | 1.2m |
