DAYTON AUDIO DSA135-PR Passive Radiator 27.9 Hz Ø13cm

A well-built passive radiator with aluminum diaphragm, designed to fit most medium-format (13cm) loudspeaker modernization/repair projects. It boasts a high excursion of 8mm, enabling it to emphasize the lower end of the spectrum while maintaining excellent sound dynamics. It can therefore be easily integrated into precision loudspeaker projects, capable of developing large volumes while remaining extremely compact.

Average votes for this product
5.0 / 5
  Based on 1 customers reviews.

By buying this product you get 2 loyalty points


Reference : 13293
New product

23,90 €tax incl.

19,92 € tax excl.

- +


Shipping date: 22-11-2024.

Orders placed before 12h (GMT+1) will generally be shipped the same day (working day).

Add to wishlist
Livraions depuis la france

Livraison depuis la france Livraison depuis la france Livraison depuis la france

Livraison depuis la France
Facturation France
SAV France

2 Years warranty

More info

DSA135 PR-5 "

Passive Radiator Aluminum ⌀13cm


DSA135-PR 5
Radiator speaker passive


A passive radiator aluminum membrane of good quality, designed to fit most of the modernization projects / speaker repair of medium format (13cm)

It has a high excursion of 8 mm, which serves to emphasize the low end while maintaining a very good dynamic sound. It can thus be easily integrated into the precision speaker projects, capable of developing high volumes while remaining extremely compact.

Its design as much as its specifications make it a very suitable radiator with the DESIGNER series in Dayton Audio. This did however not stop to offer excellent performance with other models.


To facilitate integration of the radiator and quickly achieve the best sound, the DSA135-PR comes with M5 screws, which will add weight to the radiator. This configuration lowers the resonant frequency in order to promote the natural balance of bass.

Adjusting mass resonance frequency passive radiator
Specifications
Typepassive radiator
Nominal diameter12.7cm
Resonant Frequency27.9Fs
Mechanical Q3.7Qms
total moving mass air + Load21.5gMms
Compliance of the suspension1.51 mm / NCms
emitting surface of the membrane75.4 cm²sd
Volume displaced air60.3 cm³MD
compliance equivalent volume of air12.2 litersyou
maximum excursion8 mmXmax
mechanical loss1 kg / sRms
Membrane / diaphragmCone aluminum
borderRubber
bowl materialSteel
overall external diameter13.48cm
overall depth38.1cm
drilling diameter111.76cm
Number of mounting holesx4
belt diameter10.69cm

Data sheet
Speaker Power (W RMS)NC
Speaker TypePassive Radiator
Impedance (Ω)NC
Loudspeaker diameter (mm)130.0
Diaphragm typeAluminium
Efficiency / Sensitivity (dB)N/A
Max Linear Excursion (Xmax) (mm)8.0
Lowest frequency (Hz)N/A
Highest frequency (Hz)N/A
