AUDIOPHONICS PRE-01 PGA2310 Preamplifier Volume Control Input Selector Bluetooth 5.0

An excellent volume controller

As its name suggests, the device incorporates a volume control based on a PGA2310 TI chip offering very good audio performance. This allows a very precise volume adjustment from -90 to 0dB. This chip allows to obtain a very low distortion of 0.004%, a dynamic range of 120B, a THD+N of 0.0004% at 1kHz and a crosstalk of -126dBFS.

Connectic

The Audiophonics PGA2310 offers both classic connectivity with 4x stereo RCA inputs but adds Bluetooth in version 5.0, thanks to its JL AC1820AP chip. It is thus possible to stream your music remotely from a device with this connectivity such as a smartphone or tablet for example. Bluetooth version 5.0 ensures excellent stability and transmission speed for quality listening. A Bluetooth antenna is included to improve transmission.

The output side is simply one stereo RCA to connect the PGA2310 to an amplifier. Finally, power is supplied directly via the IEC cable (not provided) from a mains socket. The unit's power supply circuit incorporates efficient multi-channel regulation to significantly reduce noise.

Power circuit

The quality of the power supply being decisive in the quality of the sound reproduction of an audio system, the Audiophonics PGA2310 benefits from a neat circuit. Thus, it integrates an efficient multi-cana regulation allowing to limit considerably the noise as well as an EMI / RFI filter allowing to filter the interferences which could generate noise.

Simple but effective design

In terms of design and ergonomics, the Audiophonics PGA2310 is simple and efficient. The components are integrated in a robust brushed aluminium housing with the most beautiful effect. A 51 x 20mm front panel screen displays both the active source from the 4 available and the sound volume, the latter up to an absolute value of 100. The white LED display provides excellent readability for easy adjustments. The unit also comes with an infrared remote control, allowing access to all settings, including volume adjustment, mute mode and source selection.

Specifications
Product type	Preamplifier Volume control Input selector
Chip	PGA2310
Distortion	0.004%
Dynamic range	120dB
THD+N	0.0004% @ 1kHz
Crosstalk	-126dBFS
Inputs	Bluetooth 5.0 4x Stereo RCA
Output	1x Stereo RCA
Output impedance	215 ohm
Display	Red LED display, 51 x 20mm
Bluetooth chip	BTM308
Housing	Brushed Aluminium
Supply voltage	230V AC
Total dimensions (With antenna + volume button)	Approx. 196 x 130 x 48mm
Value / Volume	-90dB à 0dB
Weight	820g
Color	Silver
Power cable	NOT included (available as accessories)
Package	1x Audiophonics PGA2310 1x IR Remote Control (CR2032 batteries not included)

Specifications

Product type

Preamplifier
Volume control
Input selector

Chip

PGA2310

Distortion

0.004%

Dynamic range

120dB

THD+N

0.0004% @ 1kHz

Crosstalk

-126dBFS

Inputs

Bluetooth 5.0
4x Stereo RCA

Output

1x Stereo RCA

Output impedance

215 ohm

Display

Red LED display, 51 x 20mm

Bluetooth chip

BTM308

Housing

Brushed Aluminium

Supply voltage

230V AC

Total dimensions (With antenna + volume button)

Approx. 196 x 130 x 48mm

Value / Volume

-90dB à 0dB

Weight

820g

Color

Silver

Power cable

NOT included (available as accessories)

Package

1x Audiophonics PGA2310
1x IR Remote Control (CR2032 batteries not included)

Input	Bluetooth
Input	RCA
Output	RCA
Color	Silver
Class	N/A
Remote Control	Yes
