ROSE HIFI RSA720 USB SFP Optical Fiber Hub

The Rose HiFi RSA720 SFP Optical USB Hub uses optical USB to completely block vibrations and electrical noise from external storage devices and devices. It's an excellent solution for connecting and using multiple devices, thanks to its 4 independent USB ports.

No customer reviews yet, login to write a review.

By buying this product you get 42 loyalty points


Yes, notify me when available !
Reference : 19008
New product

429,00 €tax incl.

357,50 € tax excl.
Including 0,05 € for green tax

- +


Available on order
Livraions depuis la france

Livraison depuis la france Livraison depuis la france Livraison depuis la france

Livraison depuis la France
Facturation France
SAV France

2 Years warranty

More info

Rose HiFi RSA720 Hub USB Fibre Optique SFP

Rose HiFi RSA720: front view


The Rose HiFi RSA720 SFP Optical USB Hub uses optical USB to completely block vibrations and electrical noise from external storage devices and devices. It's an excellent solution for connecting and using multiple devices, thanks to its 4 independent USB ports.

The RSA720's compact design makes it extremely easy to integrate into an audio system. What's more, it uses only high-quality materials and components to ensure durability and stable performance over time.

The Rose HiFi can completely block vibrations and electrical noise thanks to its USB ports based on an optical SFP transmitter. What's more, the RSA720 supports long-distance transmissions using optical cables, while maintaining the transmission speed of USB 3.0. Depending on the module used, the transmission distance can be extended, with stability, to hundreds of meters, offering great versatility.

For maximum compatibility, the RSA720 integrates two USB 3.0 ports and two USB 2.0 ports. What's more, it requires no driver installation.

Rose HiFi RSA720 : Connectors

How do I connect the RSA720 using an SFP optical transceiver?

Set the DIP switch on the side of the device to SFP mode and use the SFP and optical modules supplied to connect your devices as shown in the following diagram:

Rose HiFi RSA720 : SFP connection diagram


How do I connect the RSA720 using a USB-B 3.0 cable?

When connecting to a device that does not support optical SFP transmission, set the DIP switch on the side of the device to Type-B mode and use the supplied USB-B 3.0 cable as shown in the following diagram:

Rose HiFi RSA720: USB connetion diagram

Technical characteristics

Specifications
Product typeUSB / Optical SFP hub
Inputs1x USB-B 3.0
1x SFP 10G
Outputs2x USB-A 3.0
2x USB-A 2.0
General
Supply voltage12VDC 3A via Jack DC (adaptateur secteur fourni)
Dimensions (W x D x H)152 x 153.5 x 33.5mm
Weight1.2kg
ColorSilver
Package1x Rose HiFi RSA720
2x SFP modules
1x SFP LC cable 1m
1x USB-B cable 3.0 1m
1x Power adapter
1x Power cable

Data sheet
Length (m)N/A
ShieldingNC
Section (mm²)N/A
ConnectorUSB-A
ConnectorUSB-B
ConnectorOptical
Conductors material (Cable)N/A
Conductors Plating (Cable)NC
