WIMA FKP-2 Polypropylene Capacitor 5mm 100V 150pF
These WIMA FKP-2 capacitors are made of a Polypropylene dielectric. They benefit from a tolerance of 2.5%, a very low dissipation factor and a low level of dielectric absorption. Their filtering capacity allows them to be used in a wide range of applications.
No customer reviews yet, login to write a review.
No loyalty points for this product.
Reference : 6050
New product
Viewed products
WIMA FKP-2
Polypropylene Capacitor 5mm 100V 150pF
These WIMA FKP-2 capacitors are made of a Polypropylene dielectric. They benefit from a tolerance of 2.5%, a very low dissipation factor and a low level of dielectric absorption. Their filtering capacity allows them to be used in a wide range of applications. Moreover, they have an extended service life, even at high temperatures.
Technical characteristics
| Specifications | |
|---|---|
| Product type | Capacitor |
| Capacity | 150pF |
| Voltage | 100V 63VAC |
| Tolerance | 2.5% |
| Dielectric | Polypropylene foil (PP) |
| Electrodes | Metal foil |
| Temperature range | -55°C to +100°C |
| Insulation resistance (@+20°C) | ≥ 5x105MΩ |
| Dielectric absorption | 0.05% |
| Operational life | > 300000h |
| Dissipation factor (@ +20°C) | ≤ 3x10-4 @ 1kHz ≤ 3x10-4 @ 10kHz ≤ 4x10-4 @ 100kHz ≤ 10x10-4 @ 1MHz |
| RoHS | |
| General | |
|---|---|
| Dimensions | 4.5 x 6 x 7.2mm |
| Contacts spacing | 5mm |
| Tolerance (%) | 2.5 |
| Capacitor capacitance (µF) | 0.00015 |
| Rated voltage (V) | 100 |
| Capacitor type | Film capacitor |
| Capacitor format | Radial |
