WIMA FKP-2 Polypropylene Capacitor 5mm 100V 1.5nF
These WIMA FKP-2 capacitors are made of a Polypropylene dielectric. They benefit from a tolerance of 2.5%, a very low dissipation factor and a low level of dielectric absorption. Their filtering capacity allows them to be used in a wide range of applications.
No customer reviews yet, login to write a review.
No loyalty points for this product.
Reference : 12960
New product
Viewed products
![[GRADE B] IFI AUDIO IDEFENDER+ Anti Ground Loop Filter Male USB-A to Female USB-A](https://www.audiophonics.fr/65620-thumb_default/ifi-audio-idefender-anti-ground-loop-filter-male-usb-a-to-female-usb-a.jpg)
![[GRADE A] FIIO K11 DAC CS43198 Headphone Amplifier 32bit 384kHz DSD256 Black](https://www.audiophonics.fr/65622-thumb_default/fiio-k11-black.jpg)
![[GRADE A] MATRIX ELEMENT M Streamer DAC ES9028Pro WiFi AirPlay DLNA MQA 32bit 768khz DSD512](https://www.audiophonics.fr/65635-thumb_default/matrix-element-m-streamer-dac-es9028pro-wifi-airplay-dlna-mqa-32bit-768khz-dsd512.jpg)
![[GRADE A] MOONDROP COSMO Planar Magnetic Open-Back Circumaural Headphone Ø100mm 100dB 15 Ohm 13Hz-58kHz](https://www.audiophonics.fr/65641-thumb_default/moondrop-cosmo.jpg)
![[GRADE A] DAYTON AUDIO EX32VBDS-4 IMS Speaker Driver Exciter 40W 4 Ohm Ø32mm](https://www.audiophonics.fr/65646-thumb_default/dayton-audio-ex32vbds-4.jpg)
WIMA FKP-2
Polypropylene Capacitor 5mm 100V 1.5nF
These WIMA FKP-2 capacitors are made of a Polypropylene dielectric. They benefit from a tolerance of 2.5%, a very low dissipation factor and a low level of dielectric absorption. Their filtering capacity allows them to be used in a wide range of applications. Moreover, they have an extended service life, even at high temperatures.
Technical characteristics
| Specifications | |
|---|---|
| Product type | Capacitor |
| Capacity | 1.5nF |
| Voltage | 100V 63VAC |
| Tolerance | 2.5% |
| Dielectric | Polypropylene foil (PP) |
| Electrodes | Metal foil |
| Temperature range | -55°C to +100°C |
| Insulation resistance (@+20°C) | ≥ 5x105MΩ |
| Dielectric absorption | 0.05% |
| Operational life | > 300000h |
| Dissipation factor (@ +20°C) | ≤ 4x10-4 @ 1kHz ≤ 4x10-4 @ 10kHz ≤ 5x10-4 @ 100kHz |
| RoHS | |
| General | |
|---|---|
| Dimensions | 4.5 x 6 x 7.2mm |
| Contacts spacing | 5mm |
| Tolerance (%) | 2.5 |
| Capacitor capacitance (µF) | 0.0015 |
| Rated voltage (V) | 100 |
| Capacitor type | Film capacitor |
| Capacitor format | Radial |
