WIMA FKP-2 Polypropylene Capacitor 5mm 630V 2.2nF
These WIMA FKP-2 capacitors are made of a Polypropylene dielectric. They benefit from a tolerance of 2.5%, a very low dissipation factor and a low level of dielectric absorption. Their filtering capacity allows them to be used in a wide range of applications.
No customer reviews yet, login to write a review.
No loyalty points for this product.
Reference : 12961
New product
Viewed products
![[GRADE S] NEOTECH NEI-3004 Symmetrical modulation cable UP-OCC Ø 8.5mm 1m](https://www.audiophonics.fr/65235-thumb_default/neotech-nei-3004-symmetrical-modulation-cable-up-occ-o-85mm.jpg)
![[GRADE S] NEOTECH NEI-3004 Symmetrical modulation cable UP-OCC Ø 8.5mm 4m](https://www.audiophonics.fr/65232-thumb_default/neotech-nei-3004-symmetrical-modulation-cable-up-occ-o-85mm.jpg)
![[GRADE B] DAYTON AUDIO DC28F-8 Spaeker Driver Dome Tweeter Silk 50W 8 Ohm 89dB 1300Hz - 20kHz Ø2.8cm](https://www.audiophonics.fr/65229-thumb_default/dayton-audio-dc28f-8-spaeker-driver-dome-tweeter-silk-50w-8-ohm-89db-1300hz-20khz-o28cm.jpg)
![[GRADE A] LUDIC KRATOS Filtered Power Distributor 8 Filter Outlets Schuko Black](https://www.audiophonics.fr/65221-thumb_default/ludic-kratos-8-filtrer.jpg)
WIMA FKP-2
Polypropylene Capacitor 5mm 630V 2.2nF
These WIMA FKP-2 capacitors are made of a Polypropylene dielectric. They benefit from a tolerance of 2.5%, a very low dissipation factor and a low level of dielectric absorption. Their filtering capacity allows them to be used in a wide range of applications. Moreover, they have an extended service life, even at high temperatures.
Technical characteristics
| Specifications | |
|---|---|
| Product type | Capacitor |
| Capacity | 2.2nF |
| Voltage | 630V 250VAC |
| Tolerance | 2.5% |
| Dielectric | Polypropylene foil (PP) |
| Electrodes | Metal foil |
| Temperature range | -55°C to +100°C |
| Insulation resistance (@+20°C) | ≥ 5x105MΩ |
| Dielectric absorption | 0.05% |
| Operational life | > 300000h |
| Dissipation factor (@ +20°C) | ≤ 4x10-4 @ 1kHz ≤ 4x10-4 @ 10kHz ≤ 5x10-4 @ 100kHz |
| RoHS | |
| General | |
|---|---|
| Dimensions | 5.5 x 7 x 7.2mm |
| Contacts spacing | 5mm |
| Tolerance (%) | 2.5 |
| Capacitor capacitance (µF) | 0.0022 |
| Rated voltage (V) | 630.0 |
| Capacitor type | Film capacitor |
| Capacitor format | Radial |
